Moda Spring Hinge - Satin Chrome Plate
Specification
| Material | Diecast Zinc, Alloy ZP3 Brass Shaft Nylon Inserts ABS Snap-On Covers |
| Finish |
Satin Chrome Plate |
| Mounting | Concealed Screw Fix or Bolt Through |
| Minimum Hinge Clearance For Lift-Off Hinges | Â 35mm |
|
Specify
|
MODA_LHSPRING_SCP:Â Left Hand
MODA_RHSPRING_SCP:Â Right Hand
|
| Features | Spring-assisted door opening/door closing Fully Adjustable Spring to suit door - No Tension to Full Tension Spring Reversible Hold Open / Hold Closed Liftoff capability |
| Load Rating | 15Kg per hinge |
| Â |
For optimum performance - Note:Â 3 Hinges per door is recommended to prevent door bowing |
| Note |
For Bolt Through use 106C_FACEPLATE Concealed Fix Face Plate (Available in Satin Chrome Plate only) All hinges are available with or without fixings. Please nominate your requirements at the time of ordering. |
