Wall Mounted Sensor Tap – Hands-Free – Active Sense with 205mm Spout

Product image 1
Product image 2

Wall Mounted Sensor Tap – Hands-Free – Active Sense with 205mm Spout

The Touch Free Wall Mounted Sensor is a wall-mounted, sensor operated, hands free tap that is installed above sinks and basins.
It operates by sensing a hand in front of the sensor unit.
It uses a beam of invisible Infrared light which, when reflected from hand back to the sensor, operates the unit.

  • To turn tap on, place hand under spout in front of sensor
  • To turn tap off, move hand away
  • Valve stays open for 6 seconds, or as long as the hand is within sensor range
  • Maximum flow time of 45 seconds per activation reduces waste and prevents vandalism
  • Equipped with automatic hygiene flush function (1-10min/24hr) - enabled on request
  • Stainless steel sensor plate
  • WaterMark: AS/NZS 3718 WMKA 1583
  • WELS Options include: 4 and 6 Star Rating

INLET & OUTLET

Inlet Connection 15 mm (1/2”) BSP

PRESSURE

Recommended Working Pressure 100 - 500 kPa

FLOW RATE

Flow Rate 6 Star WELS rating (5 lpm aerated) supplied standard. 4 star WELS rating (8 lpm aerated / laminar flow) available on request.

TEMPERATURE

Maximum Temperature 70 °C C

POWER SOURCE

Operating Voltage 24V DC
Maximum Current 1A
Power Consumption Less than 10W

IP RATING

Sensor Protection Rating IP67 for the front panel and sensor lens. No IP rating behind panel.

SENSOR

Sensor Range 100 - 235 mm

TIME FLOW

Flow Time Runs as long as hand is within range. (Active Sense) When out of range, runs for 6 seconds. (Afterfl ow) Maximum continuous fl ow period per sensor activation is 45 seconds. (Security Time Out)
$352.51

Original: $1,175.04

-70%
Wall Mounted Sensor Tap – Hands-Free – Active Sense with 205mm Spout—

$1,175.04

$352.51
